Key Features
High Reliability LED
Integrated LED drive with independent R&D, miniature LED device leading the industry.
High Transparency
Light transmission over 90%, doesn't affect glass illumination or visibility.
Ultra-Thin & Lightweight
Only 1.8mm thick and weighs just 4.5kg/m², perfect for any glass surface.
Easy Installation
No steel structure needed. Simply stick the thin screen and connect power signal.
UV Resistant
5-10 years guaranteed without yellowing, built for long-term outdoor use.
Fire Resistant
V1 fire resistance rating with comprehensive safety certifications.
Technical Specifications
Display Specifications
Pixel Spacing6.25mm × 6.25mm
Total Pixels25,600 points/m²
LED PackageREE1515
Screen Size1000mm × 240mm
Resolution160 × 64 = 10,240
Transparency≥90%
Thickness≤1.8mm
Performance Specifications
Brightness≥3000cd/m²
Refresh Rate≥3840Hz
Gray Scale16Bit
Frame Rate≥60Hz
Viewing AngleH160° × V160°
Power Consumption~200W/m² avg
Lifespan100,000 hours
Environmental Specifications
Operating Temperature-20°C to 55°C
Operating Humidity10-90%
Protection LevelIP30
Power RequirementsAC 220V ±10%, 50-60Hz
Fire RatingV1
Control & Connectivity
Input SignalsDVI, VGA, HDMI, RJ45
Control DistanceCAT5: 100m, Fiber: 10km
Control SystemNova/Colorlight
Control ModeWiFi App, USB Drive
Color Temperature3200K-8500K
Certifications
CE
RoHS
FCC
CCC
ISO9000
